XTP0850 brushless oil pump for micro turbojet engine

X-TEAM XTP0850 brushless oil pump for micro turbojet engine

Description

The XTP0850 brushless oil pump for micro turbojet engine is a high – efficiency pumping product that integrates advanced brushless DC (BLDC) motor technology. Thanks to its delicate and compact design, powerful power output, flexible flow rate adjustment, stable pressure control, and wide adaptability, it is widely used in various liquid transportation requirements.

XTP0850 brushless oil pump for micro turbojet engine

Performance Parameters

Model: XTP0850 (equipped with a built – in BLDC motor)

Dimensions and Appearance: It features a compact design of Φ22x48mm, with a diameter of 22mm and a length of 48mm.

Voltage Range: It has a wide voltage adaptation range from 0.7V to 12V.

Power: The maximum power can reach up to 260W.

Flow Rate: The pump’s flow rate ranges from 15ml to 850ml/min (±10%).

Pressure: The maximum pressure can reach 3Mpa (at a voltage of 11V), and the minimum can be 0.2Mpa (at a voltage of 0.7V), with stable pressure adjustment capabilities.

Pump Lift and Head Height: It can achieve a vertical lift of 1 meter, meeting various vertical transportation needs.

Operating Temperature Range: It can operate in a temperature range from – 25°C to 100°C, adapting to a wide range of working environments.



Structural Features

BLDC Motor Technology: It adopts an advanced brushless DC motor, which has multiple advantages such as high efficiency, energy – saving, low noise, and a long service life.

Compact Design: Its small size not only makes it easy to carry but also suits applications with limited space.

Adjustable Flow: By adjusting the voltage or control signals, the flow rate can be precisely controlled to flexibly meet different working requirements.

Stable Pressure: It is equipped with a built – in pressure sensor and control system to ensure the continuous stability and accuracy of the pump’s output pressure.

Vertical Lift Capacity: The pump can achieve a vertical lift of 1 meter, making it suitable for vertical liquid transportation scenarios.

XTP0850 brushless oil pump for micro turbojet engine

Application Fields

Industrial Sector: It is used for liquid transportation and mixing in industries such as chemicals, pharmaceuticals, and food.

Medical Equipment: For example, it is used in the liquid circulation and transportation of medical devices like infusion pumps and hemodialysis equipment.

Portable Devices: It is widely used in portable water pumps or oil pumps for outdoor exploration, emergency rescue, and other scenarios.

Other Fields: Such as liquid circulation and filtration in home gardening, aquariums, and other application scenarios.



Precautions

Safe Operation: When using the XTP0850, ensure that the power supply is correctly connected, and avoid using it in wet or flammable and explosive environments.

Correct Installation: Be sure to install and connect it according to the steps in the product manual to ensure the stability and safety of the pump.

Maintenance: Regularly check the operating condition of the pump and replace worn – out parts in a timely manner. Also, keep the pump clean and dry to prevent debris from entering the pump.

Voltage Adjustment: When adjusting the voltage, ensure that it is within the allowable voltage range of the product to avoid damage to the pump caused by excessively high or low voltage.



If you are interested in the XTP0850 brushless oil pump for micro turbojet engine or need more product information, please feel free to contact us. We are committed to providing you with high – quality products and services to meet your needs. Whether in automation, robotics, or other high – performance application scenarios, X – TEAM motors can provide you with reliable power support. If you have any questions or need to place an order, please contact us in the following ways:

Telephone: +86 – 769 – 85228181

Email: chris@x – teamrc.com

Additional information

Product model

XTP0850

Size

Φ22x48mm

Voltage

0.7V~12V

Pump Sucker

DΦ3.0mm, DeΦ6.0mm

Pump Flowline

DΦ2.5mm, DeΦ4.0mm

Max Power

260W

ESC

30A

Pump Capacity

15ml~850ml/min(±10%)

Max Pressure

3Mpa (11V)

MIN Pressure

0.2Mpa (0.7V)

Pump Lift

1m

Pump Head

1m

Weight

68g

Working Temperature

-25°C~100°C
