XTP0450 brushless oil pump for micro turbojet engine

Description

The XTP0450 brushless oil pump for micro turbojet engine is a pumping device integrating advanced BLDC (brushless DC) motor technology, designed for users seeking high efficiency, compact design, and versatility. With its small size (Φ26×43.5mm) and lightweight (only 65g), it is suitable for various applications such as laboratories, industrial production lines, and agricultural irrigation.

Performance Parameters

Voltage Range: 0.7V to 12V (wide voltage input design ensures stable operation in different voltage environments).

Maximum Power: 140W (meets diverse fluid transfer requirements).

Electronic Speed Controller (ESC): Equipped with a 30A ESC for precise speed control and current stability, effectively protecting the motor from overload and extending service life.

Structural Features

Compact Design: Integrated motor and pump body minimize space usage, facilitating portability and installation.

High-Efficiency Energy Conversion: Achieves superior energy efficiency compared to traditional motors, converting electrical energy to mechanical power more effectively while reducing energy consumption.

Low-Noise Operation: Advanced noise reduction technology ensures quiet performance, ideal for noise-sensitive environments.

Pump Performance & Applications

Pump Head & Flow Channel:

Inner Diameter: DΦ2.5mm

Outer Diameter: DeΦ4.0mm

Flow Rate: Adjustable from 7ml to 450ml/min (±5% accuracy), suitable for fluid transfer tasks of varying scales.

Pressure Range:

Maximum: 5MPa at 11V

Minimum: 0.2MPa at 0.7V

Application Fields

Laboratories: Enables precise fluid flow and pressure control for scientific research experiments.

Industrial Applications: Ideal for high-reliability fluid transfer in industries like chemical, pharmaceutical, and manufacturing.

Agricultural Irrigation: Powers precision irrigation systems to improve water resource efficiency.

Other Scenarios: Water treatment, food processing, and more.

Precautions

Safety Operation:Ensure the power supply voltage matches the device’s specified range (0.7V–12V).Always ground the equipment to prevent electric shock.

Correct Installation: Follow the manual to securely connect the pump head and flow channel, avoiding leaks or fluid contamination.

Regular Maintenance: Clean and inspect the pump regularly. If abnormal conditions occur, stop operation immediately and after-sales service personnel.

Environmental Adaptation: While operational in broad temperature ranges, use caution in extreme conditions (e.g., high heat, humidity) and implement proper cooling/protection measures to avoid overheating or moisture damage.
