XTO3506 Brushless motor for Camera Drone and Photo Apparatus

Description

The XTO3506 Brushless motor for Camera Drone and Photo Apparatus is a brushless DC motor specifically designed for miniature drones, portable robots, and low-power industrial equipment. It is characterized by being very lightweight and having a high rotational speed, making it particularly suitable for small devices that require efficient power. The design of the XTO3506 Brushless motor for Camera Drone and Photo Apparatus focuses on energy conservation and lightweight, and it is especially suitable for scenarios with strict requirements for weight and energy consumption. Through the optimization of the electromagnetic design and low-power technology, while maintaining good performance, it can reduce energy consumption, thus achieving higher efficiency.

Performance Parameters

Model: XTO3506

KV Value: 400KV (400 revolutions per minute at no-load corresponding to each volt of voltage)

Maximum Power: 315W

Maximum Current: 13A (peak value lasting for 180 seconds)

Operating Voltage Range: 14.8V – 25V

No-load Current: 0.3A (at 10V voltage)

Resistance: 330mΩ

Efficiency Range: 4.15 – 13.51 grams per watt

Dimensions: Φ41.8×18mm

Weight: Approximately 84g

Structural Features

High Efficiency: It uses high-quality neodymium iron boron magnets and high-quality copper wire windings to ensure high efficiency and durability.

Low Noise: The special design of the stator slot shape and the rotor magnetic pole configuration makes the operation noise lower.

High RPM: With a high rotational speed design, it is suitable for applications that require high speeds.

Compact and Lightweight: Its small size and lightweight design make it suitable for applications in compact spaces.

Application Fields

Miniature Drones: Provides lightweight power for FPV racing drones and aerial photography drones, supporting high-speed flight and flexible maneuvering.

Portable Robots: Integrated into inspection robots and medical miniature robotic arms to achieve precise control and low-noise operation.

Industrial Sensor Drive: Used for small actuators in automated equipment, such as valve control and precise positioning.

Education and Scientific Research: Serves as a core component for the research and development of miniature aircraft and power system teaching experiments.

Precautions

Correct Wiring: When wiring, ensure that the power line, ground line, etc. are firmly and correctly connected to avoid the motor running in reverse or unstable power supply.

Operating Environment: These motors are suitable for both indoor and outdoor environments, but avoid long-term operation in environments with extremely high or low temperatures.

Load Control: Avoid running at the maximum throttle for a long time, as this will cause the motor and the electronic speed controller to overheat, affecting their service life.

Cooling Measures: If the motor temperature exceeds the normal range, cooling measures need to be taken, such as adding heat sinks or reducing the working environment temperature.

If you are interested in the XTO3506 Brushless motor for Camera Drone and Photo Apparatus or need more product information, please feel free to contact us. We are committed to providing you with high-quality products and services to meet your needs. Whether in automation, robotics, or other high-performance application scenarios, X-TEAM motors can provide you with reliable power support. If you have any questions or need to place an order, please contact us in the following ways:
