Description
The 2260 brushless motor for medical ventilator is a slotless brushless DC (BLDC) motor specifically designed for scenarios requiring high rotational speeds and high precision. It adopts an innovative magnetization structure with a 2-pole thickness, supports a wide voltage input range of 12-24V, and combines high efficiency with a compact design. It is widely used in high-demand fields such as model aircraft power systems, industrial automation equipment, and miniature robots.
Performance Parameters
Rotation Direction: Counterclockwise (CCW), tested at a voltage of 24V.
No-load Performance: The no-load rotational speed is 43500 rpm, and the no-load current is 0.6A.
Stall Performance: The stall torque is 448 mN.m, and the stall current is 92A.
Maximum Efficiency: When the efficiency is 77.5%, the torque is 22.4 mN.m, and the rotational speed is 41325 rpm.
Maximum Power Output: At the maximum of 96.93W, the torque is 224.0 mN.m, and the rotational speed is 21750 rpm.
No-load Rotational Speed: 43500±5% rpm.
No-load Current: Up to 1.0A.
Stall Torque: Up to 448 mN.m.
Stall Current: 92A.
Maximum Input Power (24V): 500W.
Structural Features
Rotor Structure: High-performance rare earth permanent magnet materials are used, which can generate a strong magnetic field to improve the torque output and efficiency of the motor.
Stator Structure: The stator is made by laminating high-quality silicon steel sheets, reducing core losses and improving the efficiency of the motor.
Slotless Design: This motor adopts a slotless stator design. This design can reduce iron losses and cogging effects during the operation of the motor, thereby improving the efficiency and smooth operation of the motor.
Hall Sensor Integration: The 2260 brushless motor for medical ventilator is equipped with Hall effect sensors to detect the position of the rotor for precise electronic commutation control.
Efficient Heat Dissipation Design: The motor housing is designed with a special heat dissipation structure, such as heat sinks or heat dissipation holes, to improve the heat dissipation efficiency and ensure that the motor will not overheat during high-load and long-term operation.
Lightweight Design: On the premise of ensuring the performance of the motor, the 2260 brushless motor for medical ventilator achieves the goal of lightweight through optimized design and material selection.
Application Fields
Model Aircraft and Drones: As the core of propeller drive, it supports high-speed response and explosive power output.
Industrial Automation: Drives miniature pumps, precision cooling fans, or robotic arm joints, adapting to high rotational speed requirements.
Service Robots: Used for the wheels of mobile chassis and servo steering systems, taking into account lightweight and torque density.
Power Tools: Such as small cutting machines and high-speed grinding equipment, providing instantaneous overload capacity.
Precautions
Safe Operation: Before using the motor, make sure you understand its technical parameters and installation requirements. Follow safety procedures during operation to avoid electric shock or mechanical injury.
Correct Connection: Ensure that the motor is correctly connected to the power supply and controller. Use appropriate wiring to avoid poor contact or short circuits.
Maintenance: Regularly check the operation of the motor. If you find problems such as abnormal noise, overheating, or unstable rotational speed, stop the machine immediately for inspection. When cleaning, use a dry cloth or a hair dryer to clean it, and avoid using a wet cloth or directly washing it with water.
If you are interested in the 2260 brushless motor for medical ventilator or need more product information, please feel free to contact us. We are committed to providing you with high-quality products and services to meet your needs. Whether in automation, robotics, or other high-performance application scenarios, X-TEAM motors can provide you with reliable power support. If you have any questions or need to place an order, please contact us in the following ways:
Tel: +86-769-85228181
Email: chris@x-teamrc.com
