Servo motors are widely used in automation equipment, robots and high-precision control systems, and are an indispensable and important component in modern industrial production. However, due to long-term use or excessive load, servo motors may burn out. So, how to judge whether the servo motor is burned out? In this article, X-TEAM editor will help you better identify the symptoms of servo motor damage through detailed analysis, so as to take effective maintenance and repair measures in time to avoid production stagnation.
- Observe the abnormal performance of the servo motor
One of the most direct ways to judge is to observe the working status of the servo motor. When the servo motor burns out, it often shows the following abnormal phenomena:
1) The motor cannot start: If the motor cannot start normally after the power is turned on, it may be that the coil inside the motor is burned out or the motor control part is faulty. At this time, you can check the power supply and control system of the motor to determine whether there is an abnormal signal output.
2) Motor overheating: Under normal circumstances, the servo motor will generate a certain amount of heat when working, but if the motor temperature is too high and exceeds the rated operating temperature, it may be that there is a short circuit inside the motor or the coil is damaged. At this time, you can use a thermometer to detect the surface temperature of the motor. If the temperature rises abnormally, stop using it in time and check the inside of the motor.
3) Motor vibration or abnormal noise: After the servo motor burns out, there will often be increased vibration or abnormal noise. For example, the motor will make a “buzzing” or “clicking” sound when running, which is usually caused by damage to the mechanical part inside the motor or abnormality in the motor control system.
4) Motor overload alarm: When the motor shows signs of burning out, the motor controller usually triggers the overload protection mechanism and sends an alarm signal. If the overload alarm occurs frequently and the load does not change significantly, the motor itself may be damaged.
- Check the electrical parameters of the servo motor
The electrical parameters inside the servo motor are also an important basis for determining whether the motor is burned out. Common inspection methods include:
1) Check the resistance value: Use a multimeter to detect the resistance value of the motor stator and rotor coils. Under normal circumstances, the resistance of the motor coil should meet the manufacturer’s specifications. If the resistance value is significantly low or zero, it means that the motor coil may have burned out.
2) Measure the insulation resistance: The insulation resistance of the servo motor is an important indicator to determine whether the motor has short circuit or leakage. Use an insulation resistance meter to measure the insulation resistance value of the motor. If the resistance value is too low, it means that the insulation system of the motor has been damaged, which may cause the motor to burn out.
3) Check the current waveform: Use an oscilloscope to monitor the current waveform of the motor. Under normal circumstances, the current waveform should be smooth and regular. If the waveform shows irregular fluctuations or obvious pulse fluctuations, it means that there may be problems inside the motor.
- Check the mechanical part of the servo motor
The mechanical part of the servo motor, such as bearings, rotors, etc., may also be damaged. Specific inspection methods include:
1) Check whether the motor shaft is stuck: Turn the motor shaft by hand to observe whether it is stuck or not rotating smoothly. If the motor shaft is obviously stuck, it may be due to bearing damage or overheating inside the motor, causing the rotating part to deform.
2) Check the motor housing: Whether the servo motor housing has cracks or overheating discoloration is also an important indicator to determine whether the motor is burned out. If the motor housing is charred, deformed or detached, it may be that the motor is damaged by overheating.
- How to prevent servo motors from burning out
In order to extend the service life of servo motors and avoid burning out, the following preventive measures can be taken:
1) Avoid overload operation: Overload operation is one of the main reasons for servo motors to burn out. Therefore, ensure that the motor runs within a reasonable load range and avoid overload.
2) Regular maintenance and inspection: Regularly check the electrical parameters, temperature and mechanical parts of the servo motor to detect potential problems in time and prevent small problems from turning into major failures.
3) Improve heat dissipation conditions: The servo motor will generate a lot of heat when running for a long time, so good heat dissipation conditions need to be ensured. Clean the motor radiator regularly to ensure the heat dissipation effect.
4) Use high-quality power supply and control system: Unstable power supply voltage and unreasonable control system settings can also easily cause the motor to burn out. Therefore, ensure that the power supply is stable and use a reliable quality electronic control system to accurately control the motor.
To determine whether the servo motor is burned out, it is necessary to observe the abnormal performance of the motor, detect the electrical parameters, and check the mechanical parts. If the servo motor is found to have the above abnormal symptoms, it should be stopped for inspection in time and necessary maintenance measures should be taken. At the same time, regular maintenance, avoiding overload and improving heat dissipation can effectively prevent the servo motor from burning out, extend the service life of the motor and ensure the normal operation of the production equipment.
