In the factory workshop, the hum of the motor plays the melody of production. But have you ever wondered why some motors always fail frequently, while others can run stably and efficiently? In fact, the motor installation environment plays a pivotal role. An inappropriate installation environment is like letting an athlete run in a thick cotton coat, which greatly reduces the performance of the motor. This article will explore in depth the issues related to the motor installation environment and provide you with practical optimization solutions to keep the motor in the best condition at all times.
Common problems and root cause exploration
During the operation of the motor, overheating shutdown is one of the common problems. In the hot summer, in some factory workshops without good heat dissipation measures, the motor temperature rises sharply, frequently triggers overheating protection, and the production line is forced to interrupt. Not only that, motor leakage also occurs from time to time, which not only endangers the safety of operators, but may also cause short-circuit damage to the equipment, causing huge losses to the company. In addition, the motor’s performance declines prematurely, and it should have served for many years, but it needs frequent repairs or even replacements in a short period of time, which greatly increases the operating cost.
Environmental factors are the culprits behind the scenes
Temperature influence: In a high temperature environment, the resistance of the motor winding increases, resulting in an increase in the proportion of electrical energy converted into heat energy, and the motor itself heats up seriously. For example, in a steel smelter, the workshop temperature is often as high as 50℃ or more, far exceeding the normal operating temperature range of the motor (generally 0-40℃), and the problem of motor overheating is particularly prominent. In a low temperature environment, the viscosity of the motor lubricating oil increases, and the friction increases during startup, which not only makes it difficult to start, but also aggravates the wear of components.
Humidity hazards: A high humidity environment is extremely unfavorable to the motor. Moisture can cause the metal parts inside the motor to rust and corrode, and at the same time reduce the insulation performance of the insulating material. In places with high humidity such as paper mills and printing and dyeing factories, the risk of short circuits caused by motor insulation damage is greatly increased.
Dust impurity hazards: In a dusty environment, dust easily adheres to the heat sink and windings of the motor, hindering heat dissipation and reducing heat dissipation efficiency. Moreover, dust particles entering the motor will aggravate the wear of components such as bearings. For example, in dusty factories such as mines and cement plants, motor failures caused by dust problems are common.
Installation space and foundation issues: If the motor installation space is small and the air circulation is poor, the heat cannot be dissipated in time, and it will accumulate around the motor, causing the temperature to rise. In addition, if the installation foundation is not solid, the vibration generated when the motor is running cannot be effectively buffered, which will cause the motor parts to loosen and damage in the long run.
Targeted improvement strategies
(I) Build a suitable temperature environment
Strengthen ventilation and heat dissipation: Reasonably set up ventilation equipment at the motor installation location, such as installing exhaust fans, to strengthen air convection and take away the heat generated by the motor in time. For large motors, you can consider using a forced air cooling system to carry out directional cooling of the motor through special air ducts and fans.
Take cooling measures: In high-temperature workshops, install air conditioners or air coolers to control the ambient temperature within the range suitable for the motor to work. For some special motors with high temperature requirements, water cooling can also be used to remove the heat of the motor using circulating water to ensure that the motor temperature is stable.
(II) Humidity control strategy
Improve the protection level: Choose motors with higher protection levels, such as IP54 and IP55 motors, which have better waterproof and dustproof properties and can effectively resist the erosion of humid air.
Install dehumidification equipment: Place a dehumidifier in the motor installation area to reduce air humidity. At the same time, install a heating belt inside the motor and turn on the heating regularly to remove moisture inside the motor and keep the insulating material dry.
(III) Dust and impurity removal measures
Equip with dust prevention devices: Install a special dust cover for the motor. The dust cover must have good filtering performance and can effectively prevent dust from entering the motor. And clean the dust cover regularly to ensure that its ventilation effect is not affected.
Optimize the installation position: Try to install the motor in an area with less dust. If a dusty environment cannot be avoided, the motor can be installed in a separate machine room and the machine room can be sealed to reduce dust entry.
(IV) Optimize the installation space and foundation
Rationally plan the space: Ensure that there is enough space around the motor. It is generally recommended to leave 1-1.5 meters of space around the motor for air circulation and later maintenance operations.
Reinforce the installation foundation: Use a concrete foundation and add shock-absorbing materials to the foundation to improve the stability and seismic resistance of the foundation and reduce vibration transmission during motor operation.
The far-reaching significance and implementation steps of optimizing the installation environment
(I) Significant long-term benefits
Significant cost reduction: By optimizing the motor installation environment, the motor failure rate is significantly reduced, and the number of maintenance times and maintenance costs are greatly reduced. According to statistics, a reasonable installation environment can reduce the annual maintenance cost of the motor by 60% – 80%. At the same time, the motor service life is extended, the frequency of motor replacement is reduced, and the company’s capital investment is further saved.
Production efficiency improvement: The motor runs stably, the equipment downtime is greatly shortened, the production continuity is guaranteed, and the company’s production efficiency is significantly improved. Taking a manufacturing company as an example, after optimizing the motor installation environment, the production efficiency increased by about 15%, which brought considerable economic benefits to the company.
(II) Key points for phased implementation
1.Environmental assessment stage: Comprehensively test the existing installation environment of the motor, including parameters such as temperature, humidity, and dust concentration, and check whether the installation space is reasonable and the foundation is solid, and record the existing problems in detail.
2.Scheme formulation stage: According to the results of the environmental assessment, combined with the type, power and use requirements of the motor, formulate a personalized improvement plan to clarify the required equipment, materials and construction technology.
3.Equipment procurement and installation stage: Purchase ventilation equipment, dehumidifiers, dust covers, motors with higher protection levels, etc. according to the plan, and install and debug strictly according to the construction process to ensure the normal operation of the equipment.
4.Operation monitoring and maintenance stage: After the motor is put into operation, regularly monitor the operating status of the motor, including parameters such as temperature, humidity, vibration, etc., and promptly detect and deal with problems. At the same time, do a good job in daily maintenance of the equipment to ensure long-term and stable operation of the equipment.
The motor installation environment is a key factor affecting the performance and life of the motor. Problems such as temperature, humidity, dust, and installation space and foundation may cause motor failure. By taking targeted improvement measures and optimizing the motor installation environment, the motor failure rate can be significantly reduced, the motor service life can be extended, and production efficiency can be improved. In order to ensure the stable operation of the motor, enterprises should act as soon as possible to evaluate and optimize the motor installation environment so that the motor can better serve production.
