Analysis and solution of motor encoder signal delay problem

Motor encoder signal delay will lead to position control error and system stability. This article will systematically analyze the causes of signal delay and provide a variety of effective solutions to help you optimize the encoder signal transmission quality and improve motion control accuracy.

Main causes of signal delay

1. Cable transmission delay is the most common factor. The transmission speed of signals in ordinary cables is about 2/3 of the speed of light, and each meter of cable will produce a delay of about 5ns. When transmitted over long distances, this delay will significantly affect the synchronization of high-speed motion control.
2. The delay introduced by the signal processing circuit cannot be ignored. Ordinary comparators and filters may bring 10-50ns processing delay per stage. Multi-stage series signal conditioning circuits will cause the total delay to reach hundreds of nanoseconds, seriously affecting real-time performance.
3. The fixed delay caused by the controller sampling cycle is often underestimated. The typical servo controller sampling cycle is 62.5μs (16kHz), which means that the fastest signal change will take a sampling cycle to be detected.

Hardware optimization solution

1. Selecting low-latency cables can effectively reduce the transmission time difference. The transmission speed of special coaxial cables can reach 0.9 times the speed of light. For differential signals, it is also important to maintain the symmetry of the twisted pair. Asymmetry can cause signal distortion and additional delay.
2. High-speed comparators can replace ordinary components to shorten the processing time. Selecting high-speed comparators with a rise time of less than 5ns and setting the threshold to 30%-70% of the signal amplitude can achieve the best balance between noise immunity and response speed.
3. Adding a signal pre-driver is a practical solution. Install a line driver at the output end of the encoder, such as professional chips such as AM26C31. This design can enhance the signal driving capability, reduce the rising edge degradation caused by the cable, and improve the signal quality

Software compensation technology

1. The advance compensation algorithm can predict the position change and output the control amount 1-2 control cycles in advance by establishing a motor motion model. This method requires accurate system identification, and the compensation effect depends on the accuracy of the model.
2. Delay measurement and calibration are critical. By sending test pulses and measuring the round-trip time, the total delay can be accurately quantified. The controller automatically adjusts the compensation parameters based on the measurement results to achieve dynamic calibration.
3. Digital filter optimization is very important. Replacing the conventional FIR filter with a minimum phase IIR filter can reduce group delay while maintaining the filtering effect. The filter cutoff frequency should be set to 1.5-2 times the highest frequency of the signal.

System-level optimization measures

1. Increasing the controller sampling frequency directly reduces the inherent delay. Increasing the sampling rate from 16kHz to 32kHz can reduce the delay from 62.5μs to 31.25μs. However, it should be noted that this will increase the CPU load and need to balance performance and resource usage.
2. The use of timestamp technology is an advanced solution. A high-precision clock is added to the encoder end to time-stamp each position data. The controller compensates based on the time difference. This method is particularly effective for distributed systems.
3. Optimizing the communication protocol helps reduce latency. The latency of real-time Ethernet protocols such as EtherCAT is only 100-500μs, which is much lower than traditional RS485. Choosing the right protocol and topology can significantly improve the system response speed.

Practical debugging tips

1. Use a high-speed oscilloscope to measure the actual latency, and observe the encoder raw signal and the controller received signal at the same time. By measuring the time difference between the edges of the two with the cursor, the latency contribution of each link can be accurately evaluated.
2. The closed-loop debugging method is very practical. First set a smaller compensation value, gradually increase it until the system oscillates, and then call back 20% as the optimal value. This method does not require precise knowledge of the delay time and is suitable for rapid on-site debugging.
3. Regular calibration and maintenance are important. As the equipment ages, the delay characteristics will change. It is recommended to perform a delay test once a quarter, update the compensation parameters in time, and maintain the best performance of the system.

The encoder signal delay problem needs to be solved comprehensively from the transmission medium, processing circuit, and control algorithm. Through scientific diagnosis and targeted optimization, you can significantly improve the system response speed and obtain more accurate motion control performance.
